| Тип на свързване |
Three phase |
| Ефективност |
98.4% max. efficiency, 98.0% European efficiency |
| Мощност, W |
22 500 Wp Recommended max. PV power |
| Вх.напрежение, V |
Max. input voltage: 1100 V, MPPT Operating voltage range: 200 V ~ 1000 V, Start-up voltage: 200 V, Max. number of inputs: 4, Number of MPP Trackers: 2 |
| Изх. мощност, W |
15 000 W Rated output power, 16 500 W Max. Active Power (cosf=1) |
| Изх. мощност, VA |
16 500 VA Max. apparent power |
| Изх.напрежение, V |
Rated output voltage: 220 Vac / 380 Vac, 230 Vac / 400 Vac, 240 Vac / 415 Vac; 3W/N+PE |
| Честота, Hz |
Rated AC grid frequency: 50 Hz / 60 Hz |
| Изх. ток, A |
Max. output current: 25.2 A / 380 Vac, 23.9 A / 400 Vac, 23.1 A / 415 Vac |
| Видове защита |
Overvoltage category (PV II/AC III), Input-side disconnection device, Anti-islanding/AC over-current/DC reverse-polarity protection, DC/AC surge protection, DC insulation resistance detection, Residual current monitoring unit, Arc fault protection |
| Индикатори |
LED indicators |
| Тип на охлаждане |
Smart Air Cooling |
| Работна температура |
-25 ~ 60 °C |
| Диапазон на влажността при експлоатация |
0% RH ~ 100% RH |
| Интерфейс |
RS485, WLAN/Ethernet via Smart Dongle-WLAN-FE (Optional), 4G/3G/2G via Smart Dongle – 4G (Optional), EMMA (Optional) |
| Сигурност |
EN/IEC62109-1, EN/IEC62109-2 |
| Стандарти |
IEC61727, IEC62116, IEC61683, EN50530, ABNT NBR 16149/16150, MEA/PEA, G99, NRS 097-2-1, EN50549-1, VDE4105, UTE15-712-1/VFR 2019, UNE217002, NTS631, RD244 (UNE217001), PPDS, ROGA, TOR Erzeuger, CEI 0-21:2020-12 V1, C10/C11 |
| Цвят |
White |
| Размери (Ш, Д, В), mm |
546 x 460 x 228 mm |
| Тегло, kg |
21 kg |
| Други |
IP66 |
| Приложение |
за специализирана употреба |
